Solar Power Plant

Photovoltaic solar panels: The solar panels convert sunlight into Direct Current (DC) electricity

Inverter : An Inverter then converts the DC electricity into 240-volt Alternating Current (AC) electricity suitable to power appliances in your house.
Power for your Home : Your home uses electricity firstly from the solar generated system. If your electricity use is higher than the supply available from the panels, your system gets the extra powerfrom the electricity network.
Monitoring Usage : A meter is used to monitor the electricity used from the electricity network as well as the electricity your house supplies to the network.
Excess Energy : Ifyoursolarmodule system produces more electricity than you use, the excess electricity is exported to the electricity network.

The electricity produced by your PV system is completely independent ofyour electricity usage in the house as it is connected directly to the utility grid. It will rarely be the case that your electricity production exactly matches your demand. The grid essentially acts like a battery whenever you use less energy, feeding the excess electricity into the utility. On the other hand, if you need more electricity than your PV system produces, you are backed up by the utility.Automatic Shut-off During Outages ("Anti-Islanding").To prevent injury to utility personnel working on power lines, power from the inverter to the home's electric module is shutoff immediately when there is autility outage. No power is allowed to flow out of the inverter into the utility grid from the system. This means that the house will have no electric power, either from the solar modules or from the utility, during a utility outage. The inverter will automatically re-start when utility power is restored. There is a five-minute delay before the inverter returns to normal operation, during which it synchronizes with the utility power,


On Grid/ Grid Tie System

Grid-tied or grid connected solar is a solar electricity system without batteries. Your home is hooked up to both the national grid and your UR Energy solar electricity system, so you will always have electricity available at the flick of a switch; even at night, or if it is cloudy.

Off Grid System

Off-grid connected solar is a solar electricity system with battery backup. During the day the sun shines and charges the batteries as well as supplies power to your home. During the evening or on rainy days when the sun isn't shining you use the power stored in the batteries.

Hybrid System

Hybrids are becoming more useful. The basic concept of a hybrid system is to store electricity that is generated during the day by your solar electricity system so you can use it in the evening when the sun has gone down.

Elements Solar Power Plant

  1. SOLAR MODULE:Solar panels converts sunlight into electricity.
  2. DCDB: Direct Current Distribution Box - Protect the inverter from ground fault, over current and surge.
  3. INVERTER: Converts the DC power into AC power using PV panels for your home.
  4. ACDB :Alternating Current Distribution Box - TO protect home appliances from ground fault, over current & surge
  5. SOLAR METER: Measures the generation of PV (Import).
  6. LOAD DISTRIBUTION PANEL: Distributes AC power to home
  7. BI-DIRECTIONAL METER : Measures the energy in Import & Export way.
  8. GRID : Input from concern utility (discom)provider.
